Description

  • Professional three phase separate wire feeder
  • MIG welder
  • Power indicator
  • Thermal protection
  • Digital display
  • 30 heat setting
  • Stepless wire feed setting
  • 2T/4T
  • Burn back time adjustment
  • Gas check
  • Four roller
  • Optional built-in water cooling for HGMIG500
  • Available for 15kgs or 20kgs spool



Accessories

  • MIG Torch 1 piece
  • Earth cable and earth clamp 1 piece
  • Connector cable 1 piece
  • Control cable 1 piece
  • Gas hose with hose clamp 1 piece
  • Other(contact tips, spanner, connector and hoop etc) 1 piece



Optional Accessories

  • Regulator
  • Water tank
Model HGMIG-250D Separate HGMIG-350D Separate HGMIG-500D Separate
Power Supply (V) 400 400 400
Rated Input Current (A) 14.5 23 40
Rated Input Capacity (KVA) 9.5 15.1 30.9
Output Open Circuit Voltage (V) 18-36 19-40 20-51
Welding Current Range (A) 50-250 60-350 110-500
Rated Output (A) 60%@250 60%@350 60%@500
Weldable Fe, Ss, Al Wire (mm) 0.8-1.0 0.8-1.2 1.2-1.6
Protection Class IP 21 IP 21 IP 21
Power Factor 0.96 0.96 0.96
Weight (Kg) 86 134.5 195
Packing Size (mm) 960x540x850 1000x610x850 1050x634x920
