General Features

• Precise and ease of processing both large and small size formats.
• High speed and high precision servo motion system.
• No repositioning of plate ensures optimum accuracy.
• Fiber optic laser delivery system.
• Simple operator interface and cutting database.
• CNC controlled hydraulic lift-up dual shuttle table.
• Easy accessible remote diagnostic functions.
• Long lens life because of lens protection.

Benefits at a glance

• Low investment and operating costs.
• The most cost-efficient solution for every requirement.
• Very easy to operate.
• Quick and easy installation.
• Fast loading and unloading.
• Optional flexible shuttle table sizes.
• High-position control.
• Continuous cutting with moving shuttle table.

Unique Features

• High speed low cutting cost in thin sheet metal cutting.
• Easy processing of cupper, titanium and brass.
• Low cooling capacity need, due to fiber optic delivery system, reducing energy consumption and consumable price.
• Perfect beam quality and long term power stability.
• Long cutting lens life, thanks to protective windows.
• More than 100.000 hours diode module life.
• Long life rigid machine design.

Standard Equipment

• High performance and high accuracy rack and pinion system.
• Beckhoff CNC.
• Motion system 1525 x 3050 x 100mm
• 2 kW fiber laser.
• Water chiller.
• Fiber optic beam delivery system.
• Windows 7 operating system.
• 360 degree rotating ergonomic machine control panel.
• 21,5” display 1920 x 1080 Multi-finger touch screen.
• 320 GB Program data storage.
• Transfer tables (dual palette) hydraulic lift (integrated drive system).
• Programmable high pressure air / Nitrogen gas selection 1.. 25 bar.
• Advanced precitec cutting head (with air cross blast).
• 5” & 7.5” lenses.
• Lens protective window.
• Auto nozzle cleaning and calibration.
• Standard fume extraction system.
• Parts debris drawers.
• Lantek CAD/CAM system.
• In built safety systems (light guards & full enclosure as standard).
• CE Compliance.

Software

• Easy to learn. Tutorial guide.
• All the options of Lantek Expert are fully integrated in one single program: designing a part, importing, nesting (automatic or manual), generating the cut (automatic or manual), generating the CNC etc. will be achieved from the same program without switching.
• Production Management Processes: Lantek Expert is ready for connection to production management systems (ERP) by means of automatic processes.
• Teamwork: Available for operation as a standalone productivity cell, or as part of a network system.
• Part Management and sheet store with open databases: All part info is saved and organized in databases so that users can easily locate the part and sheet required. The remnant automatically generated by the system is saved in the sheet inventory like any other sheet metal and can be used for future jobs.
• Large library of parametric parts.
• Calculation of real time and cost: Lantek
• Expert calculates cutting time and cost of the entire sheet. Taking into account the number of piercings, the cut length, the mark length, the material costs, the hourly machine rate, the cost of consumables are based on the machine data.
• 2D design. Lantek Expert includes advanced options for geometry and editing.
• 3D design. Unfolding. (Optional). Lantek Flex3D is a 3D design module which enables to design three dimensional parts and then unfold them automatically.
• The result is a part unfolded in 2D, which goes directly to the Lantek Expert database, ready for machining.
• HVAC and DUCT (Optional). Lantek Expert has a module for calculating HVAC and DUCT parts. An extensive library of figures is available.
